Heavy-duty bolting in industrial/vehicle maintenance – With up to ~1,450 Nm tightening torque across three preset stages, it’s suited for large nuts and bolts on heavy machinery or commercial vehicles.
-
Difficult to loosen fasteners – High reverse torque (~2,175 Nm) helps break free seized or over-torqued bolts.
-
Long-duration, high-power tasks – The 60 V DXP battery system provides sustained runtime for demanding jobs, while the brushless motor improves efficiency and tool life.
-
Low-visibility or confined workspaces – Built-in LED light illuminates the work area, aiding use in dark or awkward positions.
This platform is an combination of our extensive research to find optimal conditions for industrial users. Higher voltages result in less heat generated due to less current draw needed to achieve the same power while maintaining a longer run-time.
Tool Features
Technologies
Our patent-pending All-In-One motor includes the power, control & communication board along with the automatic winding stator with an interior permanent magnet design rotor, all enclosed in a die-cast cover. These one-unit components have several advantages, including weight reduction, longer lifespan, and crucially our number one design goal of efficiency as there are no additional components to cool.
DC motors have traditionally been driven by carbon brushes to power the motor. Over time these wear out and need replacing. All our motors are brushless meaning that the motor is controlled electronically without the need for carbon brushes ensuring your tool is maintenance-free.
TECHNICAL SPECIFICATIONS
Key features include:
* Advanced electronic torque and speed control
* Extended run-time and lifespan
* Three fastening modes tailored for diverse applications
* Robust metal gearbox housing for durability
* Sturdy metal gearbox housing for durability
* Integrated LED light for convenient illumination during work
Additional information
| Model | RI60164-6 |
|---|---|
| Voltage | 60V |
| Drive Size | 3/4” Square |
| Max. Tightening Torque | 450 / 600 / 1,450 Nm |
| Max. Reverse Torque | 2,175 Nm |
| No Load Speed | 0 – 900 / 0 – 1,200 / 0-1,600 RPM |
| Impacts per Minute | 0 – 2,400 IPM |
| Tool Weight (w/o battery) | 1.1 Kg |
Dimensional drawing
NOISE / VIBRATION INFORMATION
Noise Value
Sound Pressure Level (LpA )
109.4/ dB(A)
- Noise Uncertainty (K Factor) 3.0 dB(A)
Vibration Value
Average Vibration Level (Ah)*
43.1/m / s2
- Uncertainty Level(K Factor) 3 m/s2
