This platform is an combination of our extensive research to find optimal conditions for industrial users. Higher voltages result in less heat generated due to less current draw needed to achieve the same power while maintaining a longer run-time.
Tool Features
Technologies
Our patent-pending All-In-One motor includes the power, control & communication board along with the automatic winding stator with an interior permanent magnet design rotor, all enclosed in a die-cast cover. These one-unit components have several advantages, including weight reduction, longer lifespan, and crucially our number one design goal of efficiency as there are no additional components to cool.
DC motors have traditionally been driven by carbon brushes to power the motor. Over time these wear out and need replacing. All our motors are brushless meaning that the motor is controlled electronically without the need for carbon brushes ensuring your tool is maintenance-free.
TECHNICAL SPECIFICATIONS
Key features include:
* Advanced electronic torque and speed control
* Extended run-time and lifespan
* Three fastening modes tailored for diverse applications
* Robust metal gearbox housing for durability
* Sturdy metal gearbox housing for durability
* Integrated LED light for convenient illumination during work
Additional information
| Model | RI60164 |
|---|---|
| Voltage | 60V |
| Drive Size | 1/2” Square |
| Max. Tightening Torque | 450 / 600 / 1,350 Nm |
| Max. Reverse Torque | 2,050 Nm |
| No Load Speed | 0 – 900 / 0 – 1,200 / 0-1,600 RPM |
| Impacts per Minute | 0 – 2,400 IPM |
| Tool Weight (w/o battery) | 2.94 kg |
Dimensional drawing
NOISE / VIBRATION INFORMATION
Noise Value
Sound Pressure Level (LpA )- Noise Uncertainty (K Factor) 3.0 dB(A)
Vibration Value
Average Vibration Level (Ah)*- Uncertainty Level(K Factor) 3 m/s2
