Our G12 Pro Series is one of our premium ranges offering tools that are designed with power & compact size in mind. Our Brushless motor (BLDC) delivers high efficiency, precise torque, long lifespan and less maintenance. Using the same battery platform as the G12 series.
Tool Features
Technologies
Our patent-pending All-In-One motor includes the power, control & communication board along with the automatic winding stator with an interior permanent magnet design rotor, all enclosed in a die-cast cover. These one-unit components have several advantages, including weight reduction, longer lifespan, and crucially our number one design goal of efficiency as there are no additional components to cool.
DC motors have traditionally been driven by carbon brushes to power the motor. Over time these wear out and need replacing. All our motors are brushless meaning that the motor is controlled electronically without the need for carbon brushes ensuring your tool is maintenance-free.
PRODUCT VIDEO
TECHNICAL SPECIFICATIONS
- Variable speed and reversible switch for control
- 2-speed gearbox for optimal RPM selection
- Torque adjustment collar with 20 settings
- Super bright LED for improved visibility
- Battery capacity display for easy power monitoring
Additional information
| Model | RI12184 |
|---|---|
| Voltage | |
| Hammer Mode | Yes |
| Chuck | 3/8” |
| Max Tightening Torque | 50 Nm |
| No Load Speed | 0 – 1,800 RPM |
| Capacity | Wood Ø 20 mm Steel Ø 10 mm Brick Ø 8 mm |
| Tool Weight | 0.87 kg |
Dimensional drawing
NOISE / VIBRATION INFORMATION
Noise Value
Sound Pressure Level (LpA )- Noise Uncertainty (K Factor) 3.0 dB(A)
Vibration Value
Average Vibration Level (Ah)*- Uncertainty Level (K Factor) 1.5 m/s2
